How To Measure Recliner Chair Springs

All recliner parts are universal. Makes of recliners, brand names or manufactures part numbers don’t mean much.

93mm Spring Measure the total length of the spring including the hooks. Please note the offset of the hooks. One hook is shorter then the other. Break down of the measurements are – hook = 13mm, coil = 42mm, hook = 38mm TOTAL = 93mm. Wire diameter is 2.1mm.

Choose “93mm – Lockdown” from the drop down menu above, add the quantity required then “Add To Cart”

112mm Spring Measure the total length of the spring including the hooks. The hooks are symmetrical.

Break down of the measurements; hook = 22mm, coil = 68mm, hook = 22mm TOTAL = 112mm. Wire diameter is 2.1mm.

Choose “112mm – Footrest Release” from the drop down menu above, add the quantity required then “Add To Cart”

117mm Spring Measure the total length of the spring including the hooks. Please note the offset of the hooks. One hook is shorter then the other. Break down of the measurements are – hook = 16mm, coil = 61mm, hook = 40mm TOTAL = 117mm. Wire diameter is 2.1mm.

Choose “117mm – Lockdown” from the drop down menu above, add the quantity required then “Add To Cart”

TIP: To remove and fit a recliner spring, have the recliner footrest in the open position. There is no load on the spring then!

160mm Spring Measure the total length of the spring including the hooks. Please note the offset of the hooks. One hook is shorter then the other. Break down of the measurements; hook = 26mm, coil = 89mm, hook = 45mm TOTAL = 160mm. Wire diameter is 2.1mm.

Choose “160mm – Footrest Release” from the drop down menu above, add the quantity required then “Add To Cart”

180mm Spring Measure the total length of the spring including the hooks. Please note the offset of the hooks. One hook is shorter then the other. Break down of the measurements; hook = 16mm, coil = 104mm, hook = 60mm TOTAL = 180mm. Wire thickness is 2.1mm

Choose “180mm – Footrest Release” from the drop down menu above, add the quantity required then “Add To Cart”

Please choose / measure carefully as returns / reorders will incur a return fee or new postage and handling fee of $9.90
