Buy Kaidi KDYJT018-114 Actuator | Replaces KDYJT006-20

Kaidi KDYJT018-114 Replacement for KDYJT006-20

The model supplied is the genuine Kaidi KDYJT018-114, the updated replacement for the older KDYJT006-20 actuator. The older reference is retained here so you can find the correct listing from your original part number.

Looking for the KDPT006-20? Click here to view the Kaidi KDPT006-20 actuator. Check the complete model number on your original actuator before ordering.

Specifications and model references

• Brand and supplied model: Kaidi KDYJT018-114
• Older replacement reference: KDYJT006-20
• Stroke: 250mm
• Operating speed: 36mm/s
• Connections: Y-cable with five-pin and two-pin connections
• Mounting: two clevis-pin mounts

Check compatibility before ordering

Compare the original full model, stroke, mounting-end shapes, fixing-pin sizes, retracted and extended mounting-pin centre distances, electrical requirements and every connection. A similar-looking motor or matching plug alone does not confirm compatibility. Do not assume another model suffix is interchangeable.

Installation and fault diagnosis

Disconnect mains and battery power before inspection. Support the mechanism against unexpected movement and follow the chair manufacturer’s service instructions. Use matching plugs without forcing or modifying connections and keep cables clear of moving parts. Follow the actuator duty-cycle limits and use a qualified repair technician if unsure.

A chair that will not move may have a power-supply, handset, controller or wiring fault rather than a failed actuator. Diagnose the cause before replacing parts.

Help matching your actuator

Call CouchGuard on 1300 268 244 with original label, mounting and connector photos, plus mounting measurements and chair details before ordering.

Frequently asked questions

Which model will I receive?

The model supplied is Kaidi KDYJT018-114. KDYJT006-20 is the older model reference retained to help identify the replacement.

Does it replace KDYJT006-20?

Yes. KDYJT018-114 is the updated replacement supplied for KDYJT006-20. Compare the mounting measurements, electrical requirements and connections with the original installation before fitting.

What are the stroke and speed?

The actuator has a 250mm stroke and 36mm/s operating speed. Stroke is travel, not overall motor length or mounting-pin spacing.

Which mounting and connections does it use?

It uses two clevis-pin mounts and a Y-cable with five-pin and two-pin connections. Match the complete connector shape, keying, polarity and wiring with your original system.

Is this the same as KDPT006-20?

No. KDPT006-20 and KDYJT006-20 are different model references. Check the full number on your original actuator and use the separate KDPT006-20 listing if that is the part you need.

Will it replace every similar Kaidi actuator?

No. Match the original model and the complete mechanical and electrical installation. A similar model number, stroke or plug alone does not establish compatibility. Contact CouchGuard if your label has another reference.

How should the replacement be fitted?

Disconnect mains and battery power, support the mechanism against movement and follow the chair manufacturer’s service instructions. Do not force plugs or modify wiring. Keep cables clear of moving parts and use a qualified repair technician if unsure.

Will a new actuator fix every movement fault?

No. Power-supply, handset, controller and wiring faults can cause similar symptoms. Call CouchGuard on 1300 268 244 with photos of the original label, mounting ends and connections before ordering if unsure.

Replacement Parts

CouchGuard supplies replacement parts for recliners, lift chairs and lounges, including electrical and mechanical components. Use the guidance below to help identify the correct part before ordering.

Price Match Guarantee

Found the same replacement part for a lower price from another Australian supplier? CouchGuard’s Price Match Guarantee applies to all part brands and types.

We compare the complete delivered price, not just the advertised part price. This means we compare the competitor’s part price plus delivery with CouchGuard’s part price plus delivery.

What qualifies?

• The competitor’s item must be the identical replacement part.
• The part must be currently in stock and available to purchase.
• The competitor must be an Australian supplier.
• The comparison must use the complete delivered price, including delivery charges.

How to request a price match

Have a link to the competitor’s product page ready so we can verify the part, availability, price and delivery charge. Call us on 1300 268 244, or contact us by email.

Before You Buy a Replacement Part

Replacement parts can look similar while having different model numbers, dimensions, connectors or mounting points. Before ordering:

• Check the original part for a manufacturer label, model number or part number.
• Compare the connector type, dimensions and mounting points with the product listing.
• Check the product description and compatibility guidance carefully.
• Contact CouchGuard with clear photos if you are unsure which part you need.

Additional Checks for Electrical Parts

• Check that the green light on the power supply is on.
• Check the leads and connections for visible damage.
• Check whether the switch is faulty.
• If possible, test the actuator in another compatible recliner.

These checks may help identify the fault, avoid replacing a working part and save you hundreds of dollars.

Selected Product Warranties

The following warranties apply to the listed products:

• 24-month warranty on all compatible actuators.
• 24-month warranty on all genuine Okin and TiMOTION actuators.
• 12-month warranty on all genuine Kaidi, eMoMo and Mulin actuators.
• 24-month manufacturer warranty on 6000mAh and 3950mAh batteries purchased on or after 11 September 2026.
• 12-month manufacturer warranty on the 2550mAh battery pack.

All actuators supplied by CouchGuard are tested by the manufacturer before leaving its facility. If a defect becomes apparent, contact us promptly with your order details so we can assess the product under the applicable warranty.

Warranty coverage is subject to our Purchase Terms and your rights under Australian Consumer Law.

Reach out to our team today by calling 1300 268 244 or emailing info@couchguard.com.au
